Product

38100 - 8th Generation Intel® Core™ i3 Processors CPU

i3-8100

Specifications

Processor Number	i3-8100
Lithography	14 nm
Performance
# of Cores	4
# of Threads	4
Processor Base Frequency	3.60 GHz
Max Turbo Frequency	—
Cache	6 MB
Bus Speed	8 GT/s DMI3
TDP	65 W
Memory Specifications
Max Memory Size (dependent on memory type)	64 GB
Memory Types	DDR4-2400
Max # of Memory Channels	2
Graphics Specifications
Processor Graphics ‡	Intel® UHD Graphics 630
Graphics Base Frequency	350.00 MHz
Graphics Max Dynamic Frequency	1.10 GHz
Graphics Video Max Memory	64 GB
Execution Units	24
4K Support	Yes, at 60Hz
Max Resolution (HDMI 1.4)	4096×2304@24Hz
Max Resolution (DP)	4096×2304@60Hz
Max Resolution (eDP – Integrated Flat Panel)	4096×2304@60Hz
*DirectX Support**	12
*OpenGL Support**	4.5
# of Displays Supported	3
Expansion Options
Scalability	1S Only
PCI Express Revision	3.0
PCI Express Configurations ‡	Up to 1×16, 2×8, 1×8+2×4
Max # of PCI Express Lanes	16
Package Specifications
Sockets Supported	FCLGA1151
Max CPU Configuration	1
Thermal Solution Specification	PCG 2015C (65W)
T<sub>JUNCTION</sub>	100°C
Package Size	37.5mm x 37.5mm
