NUC7i7DNBE - Intel NUC Board

NUC7i7DNBE

  • Support 2 x DDR4-2400 1.2V SO-DIMM Memory (up to 32GB)
  • Support Intel® Optane™ Memory
  • Support TPM Version2.0
  • Support 1 x M.2 Card Slot (wireless)22×30 (key E) slot
  • Support 1 x M.2 Card Slot (storage)22×80 (key M) slot
  • Support 1 x SATA 6.0 Gb/s Slot
  • Support RAID 0,1
  • Ethernet Intel® i219-LM

Add to compare

Introduction







  • Support 2 x DDR4-2400 1.2V SO-DIMM Memory (up to 32GB)
  • Support Intel® Optane™ Memory
  • Support TPM Version2.0
  • Support 1 x M.2 Card Slot (wireless)22×30 (key E) slot
  • Support 1 x M.2 Card Slot (storage)22×80 (key M) slot
  • Support 1 x SATA 6.0 Gb/s Slot
  • Support RAID 0,1
  • Ethernet Intel® i219-LM

Specifications



Product Name Intel® NUC Board NUC7i7DNBE
Processor Intel® Core™ i7-8650U Processor (8M Cache, up to 4.20 GHz)
Memory 2 x DDR4-2400 1.2V SO-DIMM Memory (up to 32GB)
Ethernet 1 x Intel® i219-LM 10/100/1000 Mbps
Graphic 2 x HDMI 2.0a, 4-lane eDP 1.4
Expansion 1 x M.2 Card Slot (wireless)22×30 (key E) slot
1 x M.2 Card Slot (storage)22×80 (key M) slot
Storage 1 x SATA 6.0 Gb/s Slot
1 x M.2 Card Slot (storage)22×80 (key M) slot
Front I/O Port 2 x USB 3.0
Rear I/O Port 2 x USB 3.0, 1 x RJ45, 2 x HDMI, 1 x DC-IN (12-24V)
Internal I/O Port 2 x USB 2.0, 1 x USB 3.0, 1 x SATA 6.0 Gb/s, 1 x Serial Port
TPM 2.0
Form Factor UCFF (4″ x 4″)
