GA6702 - 2 Bays Hot Swap Mini ITX Desktop Case

GA6702

•Can support two 3.5″ hot swap HDDs ,
•An internal 3.5″ HDD, a slim ODD, and moreover, an expansion card.
•Applied on heaps of purposes such as Mini Server, Surveillance System, NVR, Cloud Server, Storage •System… and so on.


Add to compare

Introduction



G-Alantic launches GA6702 on the Computex. GA6702 is not just a Mini-ITX desktop, but the one with hot swap HDDs which highlights the uniqueness of it when compared with the cases designed by GA previously.

Besides, GA6702 can support two 3.5″ hot swap HDDs , an internal 3.5″ HDD, a slim ODD, and moreover, an expansion card. That way, GA6702 could be applied on heaps of purposes such as Mini Server, Surveillance System, NVR, Cloud Server, Storage System… and so on.

The differences from the other 19″ Rackmout or vertical server chassis , GA6702 is designed on a more compact size which fits exactly the requirement for installing in small-sized offices. It can absolutely appeals to the customers with economical requests.



Specifications




Form Factor Mini-ITX Case
Model GA6702iBK
Form Factor Mini-ITX Case
Chassis Dimensions 385(D) x 320(W) x 70(H)mm =8.62L , with Aluminum front panel
Drive Bays Flexible Combination as state form below
Front 2 x USB(V2.0), Power/Reset SW , Power/HDD LED
Power supply FlexATX 180 (CUL/TUV/ PSE/CB/CE/FCC,ErP,Active PFC)
PCI Slot 1 x Standard PCI or PCI-E
System Fan 1 x 50 x 50 x 10mm Twin Fan (Right Side)
Additional Port 2 x Serial Port ,2 x Wifi Antenna ,1 x DVI
Packing 1pc / 3.50kgs / 4.50kgs / 1.18′
Options Wall Mount, Rack Mount
Application Server , Security , i3 / i5 / i7 System , Gaminig PC



Configurations




Storage Choices
Slim ODD
3.5″ HDD
2.5″ HDD
Hot-Swap
3.5″
PCI Slot
COM Hole
Wifi Hole
DVIHole
Remarks
1.
1
1
-
2
1
2
2
1

2.
1
-
1
2
1
2
2
1

3.
-
1
1
2
1
2
2
1

4.
1
-
2
2
1
2
2
1



Accessories




Mini ITX MB D525 PCI Riser Card 2 Slots PCI Riser Card
PCI-E Riser Card 2x3.5" HDD Cage 5cm Twin FAN
Car Adaptor DC POWER KITS 80W AC Adaptor
120W AC Adaptor Stand Holdetr Slim Optical Drive
SATA ODD Cable Rack Mount  Wall Mount


2 x USB(V2.0), Power/Reset SW , Power/HDD LED

Images







Download

 ▪ GA6702-MiniITX Catalog
