Product
G4900 - Coffee Lake Intel Celeron G4900 Processors
G4900
Add to compare
Introduction
Specifications
| Specifications |
Coffee Lake Intel® Celeron® Processors |
| Essentials |
G4920 |
G4900T |
G4900 |
| Processor Number |
G4920 |
G4900T |
G4900 |
| Lithography |
14 nm |
14 nm |
14 nm |
| Performance |
| # of Cores |
2 |
2 |
2 |
| # of Threads |
2 |
2 |
2 |
| Processor Base Frequency |
3.20 GHz |
2.90 GHz |
3.10 GHz |
| Cache |
2 MB |
2.90 GHz |
2 MB |
| Bus Speed |
8 GT/s DMI3 |
8 GT/s DMI3 |
2 MB |
| TDP |
54 W |
35 W |
54 W |
| Memory Specifications |
Max Memory Size
(dependent on memory type) |
64 GB |
64 GB |
64 GB |
| Memory Types |
DDR4-2400 |
DDR4-2400 |
DDR4-2400 |
| Max # of Memory Channels |
2 |
2 |
2 |
| Graphics Specifications |
| Processor Graphics |
Intel® UHD Graphics 610 |
Intel® UHD Graphics 610 |
Intel® UHD Graphics 610 |
| Graphics Base Frequency |
350.00 MHz |
350.00 MHz |
350.00 MHz |
| Graphics Max Dynamic Frequency |
1.05 GHz |
1.00 GHz |
1.05 GHz |
| Graphics Video Max Memory |
64 GB |
64 GB |
64 GB |
| 4K Support |
Yes, at 60Hz |
Yes, at 60Hz |
Yes, at 60Hz |
| Max Resolution (HDMI 1.4) |
4096×2304@24Hz |
4096×2304@24Hz |
4096×2304@24Hz |
| Max Resolution (DP) |
4096×2304@24Hz |
4096×2304@24Hz |
4096×2304@24Hz |
| Max Resolution (eDP – Integrated Flat Panel) |
4096×2304@24Hz |
4096×2304@24Hz |
4096×2304@24Hz |
| DirectX* Support |
12 |
12 |
12 |
| OpenGL* Support |
4.5 |
4.5 |
4.5 |
| # of Displays Supported |
3 |
3 |
3 |
| Expansion Options |
| Scalability |
1S Only |
1S Only |
1S Only |
| PCI Express Revision |
3.0 |
3.0 |
3.0 |
| PCI Express Configurations |
Up to 1×16, 2×8, 1×8+2×4 |
Up to 1×16, 2×8, 1×8+2×4 |
Up to 1×16, 2×8, 1×8+2×4 |
| Max # of PCI Express Lanes |
16 |
16 |
16 |
| Package Specifications |
| Sockets Supported |
FCLGA1151 |
FCLGA1151 |
FCLGA1151 |
| Max CPU Configuration |
1 |
1 |
1 |
| Thermal Solution Specification |
PCG 2015C (65W) |
PCG 2015A (35W) |
PCG 2015C (65W) |
| T<sub>JUNCTION</sub> |
100°C |
88°C |
100°C |
| Package Size |
37.5mm x 37.5mm |
37.5mm x 37.5mm |
37.5mm x 37.5mm |
